FILE PREPARATION GUIDE
To ensure a smooth process, please follow these guidelines when submitting drawings:
-
Use closed geometry for all cut profiles.
-
Separate bend lines onto their own layer and indicate if they should be etched or cut.
-
Convert all text to outlines or curves.
-
If working from 3D models, please include a flattened DXF or drawing for each sheet-metal part.
-
When exporting from CAD software, ensure all elements are to scale at 1:1.
If you are unsure, send what you have, and our CAD team will advise.
MATERIAL THICKNESS GUIDE
